Model Type:Analog Motion Modules
Manufacturer:Allen-Bradley
Model Number:1756-M02AE
Number of Channels:2
Current Rating:Up to 1.16 A at 5.1 VDC, 3.4 mA at 24 VDC
Enclosure:Open Type
RfI Suppression:Radiated: 10 V/M with 1 KHz sine-wave 80% AM from 80 – 2000 MHz, 10 V/M with 200 Hz 50% pulse 100% AM at 900 MHz
Display:4 Character Alpha/Numeric
Mounting:Chassis
Temperature Rating:32 – 140 °F
The Allen-Bradley 1756-M02AE ControlLogix Analog Motion Modules are engineered for seamless integration into advanced industrial control systems. These modules offer unparalleled precision in motor control applications, enabling manufacturers to optimize production processes for greater output and reduced energy consumption.
Featuring dual channels for parallel control over two motors or actuators, these modules provide a flexible solution for diverse automation requirements. Their 12-bit resolution ensures exceptional accuracy in output signals, crucial for applications requiring fine-tuned adjustments.
With a wide voltage range from 0 to 10 VDC and current range of 4 to 20 mA, the 1756-M02AE modules are compatible with a broad spectrum of industrial devices, enhancing their applicability across various industries.
Equipped with a robust isolation voltage of 30 VDC, these modules safeguard against electrical interference, ensuring stable performance in harsh industrial environments. Additionally, their temperature rating spans from -40°C to 85°C, making them suitable for use in extreme conditions without compromising reliability.
Notably, the low power consumption of less than 1.5 W contributes to energy-efficient operation, reducing operational costs and environmental impact. The modules also support efficient communication through the ControlNet interface, facilitating seamless data exchange within complex automation networks.
